John Crane Type 502 Mechanical Seal for Water Pump Shaft Multi Mediums

John Crane Type 502 Mechanical Seal for Water Pump Shaft Multi Mediums
John Crane Type 502 Mechanical Seal for Water Pump Shaft Multi Mediums John Crane Type 502 Mechanical Seal for Water Pump Shaft Multi Mediums John Crane Type 502 Mechanical Seal for Water Pump Shaft Multi Mediums

Large Image :  John Crane Type 502 Mechanical Seal for Water Pump Shaft Multi Mediums

Product Details:
Place of Origin: Guangzhou, China
Brand Name: YUE MI
Certification: ISO SGS
Model Number: 502
Payment & Shipping Terms:
Minimum Order Quantity: 10/PCS
Price: consult
Packaging Details: Details Carton
Delivery Time: 5-8 word days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100/Set/Month
Contact Now

John Crane Type 502 Mechanical Seal for Water Pump Shaft Multi Mediums

Description
Type Pump Seal: John Crane Installation: Easy To Install
Spring Material: Stainless Steel, Model: 502
Product: OEM Water Pump Seal Type: Single Spring
Stationary Ring: SIC/SIC/VIT Leadtime: Fast To Ship
Oem: Specification Country Of Origin: China

John Crane Type 502 Mechanical Seal for Water Pump Shaft Multi Mediums 0



Sized(mm) d3 d6 d7 l1k l4
YM 502-12 22.6 18.5 22.5 32.5 12.0
YM 502-14 24 21 25 35.0 12.0
YM 502-16 26 23 27 35.0 12.0
YM 502-18 32 27 33 37.5 13.5
YM 502-20 34 29 35 37.5 13.5
YM 502-22 36 31 37 37.5 13.5
YM 502-24 38 33 39 40.0 13.3
YM 502-25 39 34 40 40.0 13.0
YM 502-28 42 37 43 42.5 12.5
YM 502-30 44 39 45 42.5 12.0
YM 502-32 46 42 48 42.5 12.0
YM 502-33 46 42 48 42.5 12.0
YM 502-35 49 44 50 42.5 12.0
YM 502-38 54 49 56 45.0 13.0
YM 502-40 56 51 58 45.0 13.0
Size d(mm) d3 d6 d7 l1k l4
YM 502-43 59 54 61 45.0 13.0
YM 502-45 61 56 63 45.0 13.0
YM 502-48 64 59 66 45.0 13.0
YM 502-50 66 62 70 47.5 13.5
YM 502-55 71 67 75 47.5 13.5
YM 502-60 80 72 80 52.5 13.5
YM 502-65 85 77 85 52.5 13.5
YM 502-70 89 83 92 60.0 14.5
YM 502-75 96 88 97 60.0 14.5
YM 502-80 104 95 105 60.0 15.0
YM 502-85 108 100 110 60.0 15.0
YM 502-90 114 105 115 65.0 15.0
YM 502-95 118 110 120 65.0 15.0
YM 502-100 124 115 125 65.0 15.0



Applications:
emperature
-40ºC to 150ºC, dependent on the elastomer
Pressure
Up to 40 bar
Speed
Up to 15 m/s
End play/axial float allowance
±0.1mm
Size
From 14mm to 100mm
Brand
JR
Face
Carbon, SiC, TC
Seat
SiC, TC
Elastomer
NBR, EPDM
Spring
SS304, SS316
Metal parts
SS304, SS316





FAQ

Q1: Are you a trading company or a factory?

We are a factory, so we can offer you factory prices with high quality.

Q2: Can I get samples?
Yes. You can ask for samples. Usually it's free, but you need to pay for shipping.

Q3: Can l use my own logo or design on the goods?
Yes, we provide OEM/ODMservices; your logo and design can be printed on the products.

Q4: What are your payment terms?
We accept T/T, Paypal, Western Union, and credit card payment is also welcome.

Q5: How about the delivery time?
For stock items, we can ship immediately after receiving the payment.
For other products, we need 14-25 days for mass production, which depends on the quantity and type of order.

Q6: How can we ensure the quality?
Pre-production samples are required before mass production;Final inspection is required before shipment;

Q7: 1 can't find our products in your catalog, can you customize the products for us?
Yes, customized products are available, OEM is welcome.
