Product Details:
|
| Features: | High Temperature Resistance, High Pressure Resistance, Corrosion Resistance | Product Type: | 120 Mechanical Seal |
|---|---|---|---|
| Sample: | Can Provide | Spring Material: | Stainless Steel |
| Speed: | General Speed | Material: | Carbon, Ceramic, Nitrile Rubber |
| Spring: | SUS316/SUS304 | ||
| Highlight: | 3310 3311 3312 Lower Seal,120mm Lower Seal,Flygt Pump Lower Seal |
||
| For Flygt pump | Flygt Pump 3310, 3311, 3312, 3350, 3351 |
| Shaft Size | 120mm |
| Material | TC/TC/VIT |
Product Descripition
Basic Information
| Model NO. | FS-HL |
| Performance | Corrosion |
| Balance | Balanced |
| Stationary Ring | According customer's requiriements |
| Transport Package | Carton Box |
| Trademark | YM |
| HS Code | 8484200090 |
| Production Capacity | 50000Pcs/Year |
| Standard | Standard |
| Temperature Range | -20ºC~180ºC |
| Speed Range | up to 15 M/S |
| Rotary Ring Face | Tc |
| Springs | SS304/SS316 |
| Specification | Diameter 12-75mm |
| Payment Method | T/T, Western Union |
| Origin | China |
Working Conditions:
Mediums: Water, oil, weak acids, weak bases
and other general corrosive chemical media.
Temperature: -20ºC to 120ºC
Pressure: ≤ 1.4 Mpa
Rotate speed: ≤15m/s
Materials:
Stationary Ring : Ceramic / Sic / TC
Rotary Ring : Carbon / Sic / TC /SUS304
Secondary Seal : NBR / EPDM
Spring and Metal Part: Stainless Steel
