Product Details:
|
| Seal Face: | SS304/SS316/Sic/Tc | Seal: | Submersible Pump Seal |
|---|---|---|---|
| Transport Package: | YUEMI Standard Or Customised | Replacement: | Marine Pump |
| Sku: | Marine Mechanical Seal | ||
| Highlight: | Japanese Pump Mechanical Seal,John Crane Mechanical Seal,Marine Mechanical Seal |
||
| 1. Operational Conditions: Temperature: -30ºC to +200ºC Pressure: ≤0.8MPa Speed: ≤18m/s | 2. Materials: Stationary Ring: Silicon Carbide, TC, Carbon Rotary Ring: Silicon Carbide, Carbon, TC Secondary Seal: NBR, EPDM, Viton Spring and Metal Parts: Steel |
| 3. Applications: Clean water, sewage water, oil and other moderately corrosive fluids | |
Replacement to: John Crane R00, Aesseal P08 seal, Roten UNITEN 22 seal, Hecker 400Aseal | |
| Seal Sized | D3 | D6 | D7 | D | L3 | L4 | L8 |
| 20 | 34.5 | 29.05 | 33.3 | 373 | 72 | 11 | |
| 25 | 41 | 338 | 397 | 40 | 92 | 12 | |
| 30 | 45.5 | 386 | 44.5 | 41.6 | 26 | 12 | |
| 35 | 50 | 435 | 492 | 48 | 92 | 12 | |
| 38 | 53 | 46.3 | 52 | 62.3 | 92 | 12 | |
| 40 | 55 | 481 | 54 | 48 | 92 | 12 | |
| 45 | 60 | 53 | 58.7 | 48 | 92 | 12 | |
| 50 | 66 | E65 | 65.1 | 3 | 59.1 | 92 | 16 |
| 55 | 71 | 64 | 699 | 3 | 60.7 | 92 | 16 |
| 60 | 77 | 70.4 | 76.2 | 3 | 63.8 | 92 | 16 |
| 65 | 2 | 752 | 81 | 3 | 67 | 92 | 16 |
| 70 | 88 | 799 | 85.7 | 3 | 67 | 92 | 16 |
| 75 | 92 | 847 | 905 | 3 | 718 | 92 | 16 |
| 80 | 995 | 92.6 | 98.4 | 3 | 78.1 | 92 | 16 |
| 85 | 105.5 | 989 | 104.8 | 4 | 78.1 | 92 | 16 |
| 90 | 110.5 | 103.8 | 109.5 | 4 | 829 | 92 | 16 |
| 95 | 115.5 | 108.5 | 114.3 | 4 | 82.9 | 92 | 16 |
| 100 | 121 | 113.3 | 119.1 | 4 | 829 | 92 | 16 |
| 105 | 129 | 121.2 | 127 | 4 | 89.2 | 92 | 16 |
| 110 | 134 | 126 | 131.8 | 4 | 892 | 92 | 16 |
| 115 | 139 | 130.7 | 136.5 | 4 | 892 | 92 | 16 |
| 120 | 144 | 137 | 142.9 | 4 | 95.5 | 92 | 16 |
