Product Details:
|
| Export Area: | All Over The World | Package: | Neutral Packing Or Customized |
|---|---|---|---|
| Applicable Industries: | Automobile | Type: | Fb |
| Highlight: | Rotating Shaft Automotive Car Water Pump,Mechanical Seal Automotive Car Water Pump,Blue Plastic Automotive Car Water Pump |
||
Rotany Ring (Ceramic/Slc)
tationary Ring (Plastic Carbon/Carbon'Sic)
Secondary SeaUNBR/EPDM/HNBR,WITON)
spring d Othw Parts (SUs304 5U5316)
DETAILS
| Shaft Size | 12~20mm |
| Material | Face: Carbon, SiC, TC Seat: Ceramic, SiC, TC O-rings:NBR,EPDM,FKM,Aflas,FEP,Kalrez,Chemraz etc Spring:SS304, SS316 Other Metal Parts : SS304, SS316 |
| Performance Capabilities | Temperature:-30°C to 200°C, depends on o-ring material Pressure: Up to 6bar Speed: ≤15m/s End play/axial float allowance: ±1mm |
| MODEL | D1 | D2 | D3 | 07 | L1 | L4 |
| YM FB-12 | 12.0 | 30.00 | 35.0 | 25.0 | 9.3 | 8.0 |
| YMFB-12A | 12.0 | 38.10 | 43.7 | 25.0 | 9.3 | 8.0 |
| YMFB-12B | 12.0 | 30.00 | 35.0 | 25.0 | 9.1 | 6.0 |
| YM FB-12C | 12.0 | 30.00 | 35.0 | 25.0 | 7.5 | 8.0 |
| YMFB-12D | 12.0 | 36.50 | 41.0 | 25.0 | 9.3 | 8.0 |
| YM FB-12E | 12.0 | 30.00 | 35.0 | 25.0 | 8.8 | 8.0 |
| YM FB-12G | 12.0 | 40.00 | 43.8 | 25.0 | 9.3 | 8.0 |
| YM FB-12H | 12.0 | 30.00 | 35.0 | 25.0 | 7.1 | 8.0 |
| YM FB-12L | 12.0 | 33.40 | 38.0 | 25.0 | 10.6 | 6.7 |
| YM FB-125 | 12.0 | 28.50 | 31.3 | 25.0 | 9.3 | 8.0 |
| YM FB-13 | 13.0 | 30.00 | 35.0 | 25.0 | 9.3 | 8.0 |
| YM FB-15 | 15.0 | 36.50 | 41.5 | 28.7 | 10.9 | 8.0 |
| YMFB-15A | 15.0 | 30.00 | 34.5 | 28.7 | 10.6 | 8.0 |
| YM FB-16 | 15,918 | 36.50 | 41.5 | 30.4 | 10.9 | 8.0 |
| YMFB-16C | 15,918 | 35.00 | 40.0 | 30.4 | 11.6 | 8.0 |
| YM FB-16L | 15,918 | 38.10 | 43.5 | 30.4 | 10.9 | 8.0 |
| YMFB-165 | 15,918 | 34.20 | 40.0 | 30.4 | 11.9 | 7.0 |
| YM FB-17 | 17.0 | 35.00 | 40.0 | 30.4 | 13.6 | 8.0 |
| YM F8-20 | 20.0 | 40.00 | 43.8 | 37.0 | 12.0 | 9.5 |
| YM FB-1/2* | 12,700 | 30.00 | 35.0 | 25.0 | 9.3 | 8.0 |
| YM FB-5/8 | 15,875 | 36.50 | 41.5 | 30.4 | 10.9 | 8.0 |
| YMFB-3/4* | 19,050 | 40.00 | 43.8 | 37.0 | 12.0 | 9.5 |
| YMFB-1 | 25,400 | 50.80 | 56.0 | 42.5 | 11.0 | 13.2 |
